Description
DC208TT8 is an NTN Heavy Duty Disc Bearing used primarily in agricultural disc harrows and tillage equipment.
Specifications
Bore: 1-1/8″ square (shaft size)
Outside Diameter: 3.150″ (80 mm) [bearingfin…ericas.com], [shoupparts.com]
Inner Ring Width: 1.437″
Outer Ring Width: 1.188″ [bearingfin…ericas.com], [shoupparts.com]
Seal Type: Double sealed / contact seals
Static Load Rating: 4,000 lbf
Dynamic Load Rating: 6,550 lbf
Common Cross References
Fafnir / Timken: W208PP8
NTN: 6AS09-1-1/8
John Deere: JD9286, AA14878
