Description
Donaldson P567643 hydraulic filter head assembly for HPK04 series filtration systems. Features 1-1/2″ SAE 4-bolt Code 62 inlet/outlet ports, M110 x 2 filter thread, integrated bypass valve, and reverse flow check valve for high-performance hydraulic applications.
Length 5 in
Bypass Valve Yes
Bypass Valve Setting LR 6.2 BAR
Filter-to-head Thread M110 x 2
Height 5.31 IN
Inlet Size 1 1/2 SAE 4 Bolt Code 62
Outlet Size 1 1/2 SAE 4 Bolt Code 62
Reverse Flow Check Valve Yes
Series HPK04
Length 5 IN
