Description
ABS Tone Ring Included No
Bearings Included No
Center Hole Diameter 120.000 mm
Center Hole Diameter 4.724 in
Disc Mounting [cntrc] Behind the Hub
Discard Thickness 0.984 in
Discard Thickness 25.000 mm
Hat Finish Painted
Hat ID [cntrc] in 6.693
Hat ID [cntrc] mm 170.000
Misc Holes [cntrc] 0
Mounting Bolt Hole Circle Diameter 145.200 mm
Mounting Bolt Hole Circle Diameter 5.717 in
Mounting Bolt Hole Diameter 0.591 in
Mounting Bolt Hole Diameter 15.000 mm
Mounting Bolt Hole Quantity 6
Nominal Thickness 1.102 in
Nominal Thickness 28.000 mm
Outside Diameter 11.929 in
Outside Diameter 303.000 mm
Overall Height 3.661 in
Overall Height 93.000 mm
Product Grade [cntrc] Premium
Solid Or Vented Type Rotor Vented
Surface Type Smooth
Vane Style [cntrc] Pillar
Weight [cntrc] kgs 10.200
Weight [cntrc] lbs 22.450
UPC 805890730156
