Description
AL-KO K363200 Trailer Idler Hub Kit
(also cataloged as 363200 or 9080134)
Heavy-duty, cast-iron Trailer Idler Hub Kit originally engineered by AL-KO Kober Corp (now a division of Dexter Axle). This idler hub is designed exclusively for non-braking trailer axles on light-to-medium duty commercial, utility, or stock trailers.
Specifications
Axle Weight Capacity: Designed for 5,200 lb to 6,000 lb trailer axles.
Bolt Pattern: 6 on 5.5 inches (6 lugs spaced on a 5.5″ bolt circle diameter).
Grease Seal Diameter: Includes a 2-1/8 inch (2.125″) inner diameter grease seal.
Wheel Studs: Features pre-installed 1/2-inch press-in wheel studs
Kit Inclusions
1 x Cast-Iron Idler Hub (pre-greased or raw depending on variant)
1 x Inner Bearing Cone & Outer Bearing Cone
2 x Inner/Outer Bearing Cups/Races (pre-pressed into the hub)
1 x High-Temperature Double-Lip Grease Seal
1 x Push-in Grease Cap (Dust Cap)6 x Matching 1/2″-20 Trailer Lug Nuts
Cross-Reference
Dexter Alternative Part Number: K08-213-90 / K0821390
