Description
Muncie PL-1016S-27-2 is a model from Muncie Power Products’ PL Series gear pumps, designed for use as either a hydraulic pump or motor.
PL Series Overview
Displacement Range: 14 to 30 GPM at 1000 RPM
Model 27 (as in PL-1016S-27-2) corresponds to 27 GPM
Pressure Rating: Up to 3000 PSI
Speed Rating: Up to 3600 RPM
Construction: All cast iron for durability and high-pressure capability
Design:
Bi-rotational (can operate in both directions)
4-port versatile design for flexible installation
Heavy-duty roller bearings for long life
Solid, one-piece shafts for strength
Mounting Options: 3 flange types and 5 shaft types available
