Description
0FHM0001XP – ACS Mini INLN Fuse Holder Card
Product Overview
Series: MINI® FHM
Type: In-line fuse holder
Fuse Compatibility: MINI blade fuses (32V and 58V), up to 20 amps (fuse sold separately)
Mounting Style: In-line
Ingress Protection: IP67 (dustproof and waterproof)
Body Material: Black TPV (thermoplastic vulcanizate)
Wire Leads: 14 AWG GXL stranded copper, black insulation
Lead Length: 3.7 inches (94 mm) with 0.51 inch (13 mm) end strips
Temperature Range: -40°C to +125°C
Flammability Rating: UL 94 V-0
Current Rating:
Continuous: 15 A
Max: 20 A
Voltage Rating: 58 VDC
.png/:/rs=w:300,h:300,m/cr=w:300,h:300,a=cc)
.png/:/rs=w:300,h:300,m/cr=w:300,h:300,a=cc)
