Description
Delco 8200308 is a 39MT starter motor, Caterpillar:
C10
C11
Cummins:
ISM 10.8L
ISX
Detroit Diesel:
Series 60 (S60)
Specifications
Part Number: 8200308
Model: 39MT
Type: New Starter
System Voltage: 12V
Mounting Type: SAE 3
Pinion Teeth: 11
Pinion Pitch: 6/8
Solenoid Position: 082 (82 degrees)
Rotation: Clockwise (CW)
Polarity: Insulated
Over Crank Protection (OCP): Yes
Integral Magnetic Switch (IMS): Yes
Rotatable Flange Design: Yes
Power Output: ~7.3 kW / 9.78 HP
Length: 14.32 inches (approx.)
Gear OD: 2.193 inches (55.7 mm)
