Description
Cole Hersee 5558-BP SPST Toggle Switch
Technical Specifications
Switch Type: SPST (Single Pole Single Throw)
Function: On-Off
Current Rating: 10A at 12V DC
Mounting Type: Panel Mount
Termination Style: Screw Terminals
Actuator Type: Standard Round Toggle
Actuator Length: 17.46 mm (approx. 11/16″)
Material: Nickel-plated brass actuator and stem
Panel Cutout Diameter: 11.90 mm
Bushing Thread: 15/32-32
Illumination: Non-illuminated
Ingress Protection: Not specified (likely not waterproof)
RoHS Compliance: Yes (RoHS3 Compliant)
REACH Status: Unaffected
