Technical Specifications
Manufacturer: Cole Hersee (a Littelfuse brand)
Series: 551 Extra Heavy Duty
Switch Type: Toggle
Circuitry: SPDT (Single Pole Double Throw)
Switch Function: ON – OFF – ON
Current Rating:
30A @ 6–12V DC
15A @ 24–36V DC
Voltage Rating: Up to 36V DC
Mounting Style: Panel Mount
Termination Style: Screw Terminals (3 screws)
Handle Material: Chrome-plated brass
Handle Length: ~26.98 mm (1 1/16″)
Housing: Zinc-plated die-cast
Bushing Size: 15/32″-32 thread with keyway
Panel Thickness Compatibility: Up to 3/16″ (4.76 mm)
Contact Material: Silver-plated
Ingress Protection: Not specified
Illumination: Non-illuminated
Environmental Compliance: RoHS3 compliant, REACH unaffected
